AMMONIA LEAK DETECTION SYSTEM

INTRODUCTION

In response to today’s ever-increasing demand for speed, accuracy and performance Manik Engineers has introduced the Ammonia Leak Detection system for Cold Chain Solutions. The Manik Ammonia Leak Detection system provides precise, stable readings and even in demanding environments is simple to operate, fast, reliable and built to las. We supply Ammonia Leak detection system in various countries like Vietnam, Indonesia, Malaysia, Philippines, UAE, Saudi Arabia, Egypt, South Africa, Sudan, and Peru

Liên hệ

Thông tin sản phẩm

KEY FEATURES:

Three Level Alarm for each channel
First 'Contamination'at 50 ppm
Second 'Early Warning' at 150 ppm
Final'Alarm' at 250 ppm
These alarms have been designed as per international
guidelines.

• Single point and mulitpoint Alarm Units
• Operates on 230VAC, 50Hz, with inbuilt power supply for Ammonia Transmitters
• In-built Alarm Hooter
• LED Indication for Each Channel Contamination,
• Early Warning and Alarm Status • Overload protected
• Robust case for long life in harsh environments
• Continuous monitoring • Low zero point drift
• Stable Positioning• Long life sensor
• Easy maintenance / calibration • Reverse polarity protected
• 4 – 20 mA analog signal output from Transmitter
• 7' TFT Color touch screen graphic display
• Set point and relay output for individual channel.
• SMS alert on 5 phones
• LAN / Rs485 modbus protocol PLC / SCADA interface

LIMITS OF TOXICITY FOR AMMONIA

Minimum detectable concentration 10 ppm
TWA value 50 ppm
Serious irritation level 250 ppm
Limit to tolerable breathing 500 ppm
