HIGH PRESSURE STOP CHECK VALVES AND CHECK VALVES TYPE : MHPSCV & MHPCV

Maximum working pressure: 798 psi g (55 bar g)
Fluid temperature range: -60°C to + 150°C (–76°F to 302°F)
Application: Ammonia, Fluorocarbons, Carbon Dioxide
Material: Body: LCC A352 Cast Steel Body
Valve Cone: EN1A
Valve Stem: SS304
Packing Gland: SS304
Seat: PTFE
Connections: DN15-125 – Socket/Butt Weld
Reliable Back Seating
DN15-65 available in stainless steel upon special request.

Liên hệ

Thông tin sản phẩm

MHPSCV is a combination stop valve and normally-spring-closed check valve.Whereas MHPCV is a simple angle-type check valve. Both of these are available in an angle way only. Valves open wide for full flow in the arrow's direction on the valve body and promptly reseat when reverse flow occurs. Optimum opening characteristics are attained due to Precisely Cut Ports (MHPSCV/MHPCV 50-125).Primary characteristics of these valves include efficient functioning at low differential pressure,easy inspection and maintenance.These valves have stainless steel stems with back seating for seal replacementunder working conditions. The internal design minimizes pulsations.

Size in SI	Size in inch	Item Description	Price List
MHPSCV Stop Cum Check Valve - Angle way
15	1/2"	MHPSCV 15 D ANG STOP/CHECK VALVE	134
20	3/4"	MHPSCV 20 D ANG STOP/CHECK VALVE	143
25	1"	MHPSCV 25 D ANG STOP/CHECK VALVE	197
32	1 1/4"	MHPSCV 32 D ANG STOP/CHECK VALVE	226
40	1 1/2"	MHPSCV 40 D ANG STOP/CHECK VALVE	235
50	2"	MHPSCV 50 D ANG STOP/CHECK VALVE	280
65	2 1/2"	MHPSCV 65 D ANG STOP/CHECK VALVE	467
80	3"	MHPSCV 80 D ANG STOP/CHECK VALVE	535
100	4"	MHPSCV 100 D ANG STOP/CHECK VALVE	707
125	5"	MHPSCV 125 D ANG STOP/CHECK VALVE	1187
MANIK CHECK VALVE ANGLE TYPE MHPCV
15	1/2"	MHPCV-15 ANGLE CHECK VALVE	104

20	3/4"	MHPCV-20 ANGLE CHECK VALVE	111
25	1"	MHPCV-25 ANGLE CHECK VALVE	152
32	1 1/4"	MHPCV-32 ANGLE CHECK VALVE	177
40	1 1/2"	MHPCV-40 ANGLE CHECK VALVE	184
50	2"	MHPCV-50 ANGLE CHECK VALVE	218
65	2 1/2"	MHPCV-65 ANGLE CHECK VALVE	363
80	3"	MHPCV-80 ANGLE CHECK VALVE	412
100	4"	MHPCV-100 ANGLE CHECK VALVE	541
125	5"	MHPCV-125 ANGLE CHECK VALVE	935
